Intel Keyboard Buffer Information Disclosure Vulnerability Intel ID:
INTEL-SA-00016
Product family:
Intel® Desktop and Intel® Mobile Boards
Impact of vulnerability
Information Disclosure
Severity rating:
Moderate
Original release:
Aug 25, 2008
Last revised:
Aug 25, 2008
Summary:
Specific Intel BIOS's fail to sanitize user input entered during the Power On Self Test, POST, process. Under certain situations this issue could potentially result in a disclosure of information.

Description:
A new BIOS is available on select Intel motherboards to ensure proper sanitization of user input entered during the Power On Self Test, POST, process. This new BIOS will properly clear user input before the launch of the Operating System. This new BIOS will prevent exploitation by a malicious local user or software running on the local system to expose pre-execution passwords.

Affected products:
DQ35JO, DQ35MP, DG35EC, DP35DP, DG33FB, DG33BU, DG33TL, DX38BT, MGM965TW (Mobile) and MGM965JB (Mobile).

Recommendations:
Recommendations:
While Intel is not aware of any use of the vulnerability described in this advisory, Intel has made changes to the BIOS firmware of affected products to prevent this issue.
To determine if you are at risk follow these steps:
1. Reboot your system.
2. Hit F2 to enter setup
3. The BIOS version will be on the first setup page displayed.
4. Look at the first portion of the BIOS version. For example - JOQ3510J.86A.0942.2007.1210.2204.
5. Then look at the date string section - JOQ3510J.86A.0942.2007.1210.2204.
6. If your BIOS has one of the numbers listed in the first section below and the date code section is older you need to update your BIOS.
For the Intel products listed in the Affected Products table, Intel has made available updated BIOS firmware per the table below. The updated BIOS firmware is available at http://support.intel.com. From this web page select 'Download Center'. On the 'Search Downloads' line, enter the affected product name (for example DG33BU) and click search. Click on the found product, select your operating system and click 'Go'. Next click on the BIOS title, then follow the instructions on the download page for downloading and installing the BIOS update. Several options are available.
DQ35JO
JOQ3510J.86A.0942.2008.0807.1958
DQ35MP
JOQ3510J.86A.0942.2008.0807.1958
DP35DP
DPP3510J.86A.0484.2008.0805.2031
DG33FB
DPP3510J.86A.0484.2008.0805.2031
DG33BU
DPP3510J.86A.0484.2008.0805.2031
DG33TL
DPP3510J.86A.0484.2008.0805.2031
MGM965TW (Mobile)
TW96510J.86A.1157.2008.0730.1429
D945GCPE
PE94510M.86A.0065.2008.0801.1803
DX38BT
BTX3810J.86A.1814.2008.0807.2334

Server board packs two Intel Xeon processors.



Kontron has entered the server board market segment with the release of KTC5520-EATX, adding a server class category to its extensive portfolio of embedded and basic motherboard products.
The cost-effective Kontron KTC5520-EATX SSI EEB-compliant server board is designed with a feature-set and two new Intel Xeon 5518 45nm quad-core processors. Its extreme performance, high I/O bandwidth and reliability—backed by a up to 7-year life-cycle support program—suit OEMs designing a multitude of applications found in the medical imaging, simulation, storage and multimedia telecom and data center markets.
"We are extremely excited to introduce this server board," said Benoit Robert, executive director, product management at Kontron. "For five years, Kontron has been rapidly expanding its embedded motherboard business and, with its long design experience with server class, embedded Intel processors such as in our AdvancedTCA and CompactPCI bladed products, the business case was there to parley that experience into our motherboard portfolio. Thanks in large part to the design-in of the new Intel Xeon microarchitecture, early reaction from clients have been strong and immediate."
Remote managementAn attractive selling point for network managers is the server board's built-in ability to be fully managed remotely. Kontron uses an integrated management processor (IMP) that integrates VGA/2D, BMC and KVM/VM over IP to support real-time access with full control by keyboard, video monitor and mouse (KVM) and virtual media (VM) by a single local computer from anywhere, at any time. Intelligent Platform Management Interface (IPMI) 2.0 compliant using IPMI over LAN, the server board provides the OS-independent and cross-platform interface for monitoring the server system's temperature, voltage, and fan status, among other items, and permits out-of-band management even when the main processors are not powered-in.
In addition, KVM and VM over IP allow administrators to install software from a remote drive (floppy, CD/DVD-ROM, flash device, HDD) to target servers for convenient installation. At the same time, the KVM/VM function enables faster troubleshooting by fixing server problems from anywhere, while IPMI proactively sends alarms about environmental issues that could threaten the server's services, therefore reducing system downtime and operation costs.
The Kontron KTC5520-EATX server board also provides one dual port GbE controller for external connectivity, support for iSCSI storage technology and boot-up via iSCSI, and expansions via two USB headers (flash drive compatible), one TPM 1.2 header, one PCI 32 bits/33MHz slot, one PCIe x4 Gen1 slot and four x8 PCIe Gen2 slots. It also features six SATA II connectors, four USB 2.0 ports, seven fan headers, VGA, legacy PS/2 keyboard/mouse and HD audio interfaces.

Intel ships 32nm Westmere samples to PC makers.


Back in February Intel announced an update to its revealing that it is accelerating the process shrink by skipping some CPUs that were going to arrive later this year – namely some 45nm dual-core Nehalem variants. The first Intel processors to be built using 32nm technology are codenamed Westmere and, according to information revealed by CEO Paul Otellini such chips have already been sampled to around 30 laptop and desktop PC manufacturers for testing.
Otellini said that Westmere will ship in volume later this year and could be on sale in PCs by early 2010. The new chips are basically die-shrink versions of the current 45nm Nehalem family of processors, but will come in a two-chip package configuration, where a die containing a graphics core and the memory controller will sit alongside the CPU die. There will be a desktop variant known as Clarkdale, comprising of two cores with hyper-threading technology, and a mobile chip codenamed Arrandale with the same arrangement.

Intel® PRO/1000 GT Desktop Adapter..

Built on Intel lead-free technology1, the Intel® PRO/ 1000 GT Desktop Adapter is the environmentally friendly way to bring Gigabit performance to your desktop at no extra cost. The GT Desktop Adapter conforms to the European Union's Restrictions on the use of Hazardous Substances2 and Japan's White Goods Recycling Act.

Simplify installation and maintenance with Intel® SingleDriver™ technology.

High-performing, auto-negotiating 10/100/ 1000 connection.

Product information

Features and benefits

10/100/1000 Mbps Allows easy migration to faster networks as current 10/100 Mbps networks move to Gigabit, without requiring reconfiguration by IT staff-saving time, money and downtime
Intel® 82541PI Gigabit Controller Enhances high performance and reliability
Compatible with Fast Ethernet and Ethernet Reduces deployment and training costs and enables easy, quick migration to Gigabit Ethernet
Peripheral Component Interconnect (PCI) 2.3 32-bit 33/66 MHz Designed for high performance on desktop bus architecture
Category-5 Cabling Uses pre-existing 4-pair cabling and saves re-wiring cost
Interrupt Moderation Significantly reduces CPU utilization and increases throughput
Advanced Configuration and Power Interface (ACPI), Wake on LAN* (WoL), Preboot Execution Environment (PXE) Allows lower power consumption, remote wake and remote booting
Simple Network Management Protocol (SNMP)/Desktop Management Interface (DMI), Wired for Management (WfM) Lowers Total Cost of Ownership (TCO) through improved manageability
Meets IEEE 802.3ab* Technology Supports standards interoperability
Advanced Cable Diagnostics Dynamically tests and reports network problems (interrupts, error rate, cable length) and automatically compensates for cable issues such as crossover cable, wrong pin-out and polarity
Support for Many Network Operating Systems (NOSs) Enables widespread deployment.

Intel® Ethernet Desktop Adapters

http://cache-www.intel.com/cd/00/00/17/95/179548_179548.jpg10 Gigabit Ethernet
Server Adapters
Intel’s fastest connection for high-performance
servers.
1. Designed for Multi-Core Processors
2. Optimized for Virtualization
3. Unified Networking over Ethernet
Ideal for transferring large data blocks in:
• High-performance computing and storage clusters, database,
and backup servers
• CAD/CAM nodes, modeling and graphics
• Data modeling and simulations
• Financial forecasting
• Video editing and digital imaging
• Network backbones
For short reach, lowest cost, and lowest power in high
density rack server to top of the rack switch connections,
specify the Intel® 10 Gigabit AF DA Dual Port Server Adapter.
For CX4 copper (up to 15 m), specify the Intel® 10 Gigabit
CX4 Dual Port Server Adapter.
For medium reach in multi-mode fiber (up to 300 m),
specify the Intel® 10 Gigabit XF SR Server Adapter.
For long reach in single-mode fiber (up to 10 km), specify
the Intel® 10 Gigabit XF LR Server Adapter.
PCI Express Adapters
for Gigabit Ethernet
Enhance Gigabit Ethernet performance with a
broad selection of PCI Express adapters for servers,
workstations and desktops.
• Reliable, proven 6th generation Gigabit Ethernet technology
from Intel.
• Scalable PCI Express interface provides dedicated I/O bandwidth
for I/O intensive networking applications.
• Quick and comprehensive configuration and management with
the Intel® PROSet for Microsoft Device Manager* software.
• Flexibility with iSCSI Boot and choice of quad-, dual-, and singleport
adapters in both fiber and copper.
• Lead-free technology for use in worldwide markets.
• Security IPsec provides data protection between the host and
destination devices of network.
Quick and Easy Adapter
Management
Powerful point-and-click configuration tool for
advanced adapter features, connection teaming, even
VLANs, with Intel® PROSet for Microsoft* Device
Manager.
• Convenient access to Intel® PROSet Utility, now integrated
in Microsoft Device Manager.
• Simple, integrated
tools make it easy to
manage and troubleshoot
Ethernet connections in
both servers and client
computers.
• Supports multi-vendor
teaming for adapter
compatibility with most
on-board connections.
©2008 Intel Corporation. All rights reserved. Intel, the Intel logo,
and Intel SingleDriver are trademarks or registered trademarks
of Intel Corporation or its subsidiaries in the United States and
other countries.
*Other names and brands may be claimed as the property of
others.
Printed in USA/0708/MBR/PMS/PP/2.5K 252454-012US
Intel® Server and Desktop
PCI Express* Adapters
Product Selection Guide
Intel® Server and Desktop
PCI Express* Adapters
Connectivity you can count on
Compatibility tested for trouble-free interoperability with
network infrastructure elements.
Broad selection from 10/100 Mbps to 10 Gbps, for copper or
fiber, from PCI to PCI Express*, in single- to quad-port configurations.
Performance and reliability backed by more than 25 years
of network connectivity experience and Intel worldwide customer
support.
Easy installation and management with Intel® PROSet Utility
for Microsoft Device Manager* and other tools.
Worldwide availability and environmentally friendly for
compliance with global market requirements.
Multi-Port Gigabit
Server Adapters
Increase uptime, scalability and performance
with four Gigabit Ethernet ports in one slot.
• Conserve server slots with a selection of dual- and
quad-port Intel® Server Adapters for flexible network
connectivity.
• Increase reliability and performance by teaming ports
together for automatic failover and scalable server links, or
utilize multiple network segments and VLANs.
• Simplify multi-port link aggregation, adaptive load
balancing and fault tolerance with Intel® Advanced
Network Services software for connection teaming.
• Scale server performance with Intel® Virtualization
Technology for Connectivity (Intel® VT-c).
• Easy connection management with Intel® PROSet for
Microsoft Device Manager software.
• Supports multi-vendor teaming for adapter
